Fayette County Marcellus Shale Permits 9/7/15 - 9/20/15

In this issue there are several applications of Application Type Notification for permits dating back several years. These applications are probably status notices, and probably do not indicate new work being done on these sites.

Click the map to enlarge
Map of
          Permits 9/7/15 - 9/20/15

Map Key
Red dots: items in this permit list with an exact location.
Blue stars: Marcellus Gas Well Water Sources.
Municipality shading: number of "facilities", with each well counting separately
(includes the red dots):
gray: 0
pale turquoise: 1
turquoise: 2
pale blue: 3
middle blue: 4
dark blue: 7
dark purple: 11
purple: 19
(Color coding may differ from one issue to the next.)
(Note if a project spans multiple municipalities -- e.g. a pipeline -- it will show in the count for each municipality.)

The number of facilities also follows the municipality name in brackets.

Municipality counts are based on the way the permit is listed by DEP; DEP has been known to get a municipality wrong.

Locations in brackets identify a precise location used to locate a surrogate for the actual site being permitted (e.g. locating a well pad or pipeline by the known location of a well.) Locations labeled beginning with "~" and ending in "[?]" are approximate and speculative based on inferences using on-line property and lease records. These are marked in the text as "[Approximate, Speculative]

Cross-hatching: Environmental Justice Areas
Yellow triangles: Compressor Stations
Crosses: Unconventional well permits (may not have been drilled)
Green: "Natural areas", e.g. state game lands, state forests

More Maps

Zoomed map 9/7/15 -
                9/20/15

Source: Pennsylvania Bulletin

26154101. Wampum Hardware Co. (636 Paden Road, New Galilee, PA 16141). Blasting activity permit for commercial development for the Uniontown Borrow Pit, located in South Union Township, Fayette County. Blasting permit issued: August 31, 2015.
<http://www.pabulletin.com/secure/data/vol45/45-38/1692c.html>
[See Notes.]

-------------------------
Source: eNOTICE (+ PA Oil and Gas Mapping)

Authorization ID:    1082645
Permit number:    ESX10-051-0021
Site:    MARUSZEWSKI WELL SITES ESCGP-EXPEDITED
Client:    ATLAS RESOURCES LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    07/27/2015
Status:    Issued on 9/8/2015
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1082645>
Location [of MARUSZEWSKI UNIT 1 (surrogate)] : 39.958166,-79.779855 <http://osm.org/go/ZWpxMIX6--?m=>
Municipalities: Menallen Twp
[See Notes.]

Authorization ID:    1088124
Permit number:    ESX11-051-0032
Site:    DC CONNECTOR PIPELINE ESCGP-EXPEDITED
Client:    LAUREL MTN MIDSTREAM OPR LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    09/01/2015
Status:    Pending
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1088124>
Municipalities: Franklin Twp
[See Notes.]

Authorization ID:    1088126
Permit number:    ESX11-051-0022
Site:    MUTNANSKY 1469 TO 20/24" TRUNK ESCGP-EXPEDITED
Client:    LAUREL MTN MIDSTREAM OPR LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    09/01/2015
Status:    Pending
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1088126>
Municipalities: Franklin Twp: Menallen Twp: North Union Twp
[See Notes.]

Authorization ID:    1088129
Permit number:    ESX11-051-0016
Site:    CONSTANTINE TO LYNN PIPELINE ESXGP-EXPEDITED
Client:    LAUREL MTN MIDSTREAM OPR LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    09/01/2015
Status:    Pending
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1088129>
Municipalities: Franklin Twp, Jefferson Twp, Menallen Twp, Perry Twp, Redstone Twp, Rostraver Twp, Westmoreland County
[See Notes.]

Authorization ID:    1088193
Permit number:    26-00588
Site:    SHAMROCK COMP STA
Client:    LAUREL MTN MIDSTREAM OPR LLC
Authorization type:    Minor Source Operating Permit
Application type:    New
Authorization is for:    FACILITY
Date received:    09/03/2015
Status:    Pending
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1088193>
Location: 39.918333,-79.825 <http://osm.org/go/ZWpasXGm--?m=>
Municipalities: German Twp [an Environmental Justice Area]

Authorization ID:    1082630
Permit number:    ESX11-051-0036
Site:    CRISTOFEL WELL MCLS NO. 1510 ESGPX-EXPEDITED
Client:    CHEVRON APPALACHIA LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    07/27/2015
Status:    Issued on 9/11/2015
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1082630>
Municipalities: Jefferson Twp
[See Notes.]

Authorization ID:    1082637
Permit number:    ESX12-051-0006
Site:    LIPTAK WELL SITE ESCGP-EXPEDITED
Client:    CHEVRON APPALACHIA LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    07/27/2015
Status:    Issued on 9/11/2015
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1082637>
Municipalities: Jefferson Twp
[See Notes.]

Authorization ID:    1083210
Permit number:    ESX09-051-0016
Site:    JACKSON FARMS WELL SITES ESCGP-EXPEDITED
Client:    CHEVRON APPALACHIA LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    07/24/2015
Status:    Issued on 9/11/2015
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1083210>
Municipalities: Redstone Twp
[See Notes.]

Authorization ID:    1083209
Permit number:    ESX10-051-0028
Site:    BURNWORTH FRESHWATER IMPOUNDMENT ESCGP-EXPEDITED
Client:    CHIEF OIL & GAS LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    Notification
Authorization is for:    SITE
Date received:    07/24/2015
Status:    Issued on 9/11/2015
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1083209>
Location [of BURNWORTH UNIT 1H]: 39.808139,-79.390917 <http://osm.org/go/ZWrB22cP--?m=>
Municipalities: Henry Clay Twp
[See Notes.]

Authorization ID:    1079972
Permit number:    ESX15-051-0010
Site:    ZALAC WELL CONNECT ESCGP-2 EXPEDITED
Client:    LAUREL MTN MIDSTREAM OPR LLC
Authorization type:    Expedited E&S Stormwater General Permit 1
Application type:    New
Authorization is for:    SITE
Date received:    07/06/2015
Status:    Issued on 9/15/2015
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1079972>
Location: 39.910928,-79.850738 <http://osm.org/go/ZWpaL4lE--?m=>
Municipalities: German Twp [an Environmental Justice Area]

Authorization ID:    1084207
Permit number:    ESG15-051-0011
Site:    NEMACOLIN 7008 WELL PROJECT ESGP-2
Client:    T & F EXPLORATION LP
Authorization type:    Erosion and Sediment Control GP-2
Application type:    New
Authorization is for:    SITE
Date received:    08/07/2015
Status:    Pending
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1084207>
Location [of NEMACOLIN 7008-1H]: 39.805666,-79.520969 <http://osm.org/go/ZWprWth4--?m=>
Municipalities: Wharton Twp

[Arguably off-topic]:
Authorization ID:    1087728
Permit number:    26-00535
Site:    FAYETTE ENERGY FACILITY
Client:    DYNEGY OPERATING COMPANY
Authorization type:    Major Facility Operating Permit
Application type:    Transfer
Authorization is for:    FACILITY
Date received:    08/14/2015
Status:    Pending
Sub-Facility ID    Sub-Facility Name    Description
890030     AUXILIARY BOILER     Combustion Unit
805954     CGT TRAIN 1 COMBINED CYCLE TURBINE     Process
805959     CGT TRAIN 2 COMBINED CYCLE TURBINE     Process
1036141     CONDENSER COOLING TOWER     Process
1036139     DIESEL EMERGENCY FIREWATER PUMP ENGINE(265 BHP)     Process
1036140     DIESEL EMERGENCY GENERATOR ENGINE (489 BHP)     Process
1095705     OXIDATION CATALYST UNIT 1     Air Pollution Control Device
1095706     OXIDATION CATALYST UNIT 2     Air Pollution Control Device
1095701     SCR UNIT 1     Air Pollution Control Device
1095702     SCR UNIT 2     Air Pollution Control Device
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1087728>
Location: 39.857441,-79.913856 <http://osm.org/go/ZWpM9Un6--?m=>
Municipalities: German Twp [an Environmental Justice Area], Masontown Boro

Authorization ID:    1089542
Permit number:    051-24635
Site:    YODER WELL PAD ESCGP-2 EXPEDITED
Client:    CHEVRON APPALACHIA LLC
Authorization type:    Drill & Operate Well Permit
Application type:    New
Authorization is for:    FACILITY
Date received:    09/14/2015
Status:    Pending
Sub-Facility ID    Sub-Facility Name    Description
1186051     YODER 1     Well
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1089542>
Conservation Well: N
Well Configuration: Vertical Well
Location: 39.975683,-79.923763 <http://osm.org/go/ZWpZzGbq--?m=>
Municipalities: Luzerne Twp

[Repeat Listing:]
Authorization ID:    1082707
Permit number:    051-24633
Site:    SIEGEL 1 OG WELL
Client:    CHEVRON APPALACHIA LLC
Authorization type:    Drill & Operate Well Permit
Application type:    New
Authorization is for:    FACILITY
Date received:    07/13/2015
Status:    Issued on 8/12/2015
Sub-Facility ID    Sub-Facility Name    Description
1181842     SIEGEL 1     Well
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=1082707>
Location: 39.968972,-79.968794 <http://osm.org/go/ZWpZSBiu--?m=>
Municipalities: Luzerne Twp
Unconventional Well: Y
Well Configuration: Vertical Well
Conservation Well: N
Anticipated Maximum TVD: 7768
Full Permit: <http://www.depgis.state.pa.us/PaOilAndGasMapping/PdFFetcher.ashx?Doc=D0fOzFwR%2bi1ySQNoaw2GcQ%3d%3d&ext=PDF>
[See Notes.]

-------------------------
Source: DEP Oil and Gas Compliance Report

OPERATOR: CHEVRON APPALACHIA LLC
INSPECTION_ID: 2407288
INSPECTION_DATE: 09/08/2015
INSPECTION_TYPE: Drilling/Alteration
API_PERMIT: 051-24617
FARM_NAME: ZALAC UNIT 10H
UNCONVENTIONAL: Y
SITE_ID: 786409
SITE_NAME: ZALAC UNIT #5-11H WELL SITE ESCGP-2 EXPEDITED
FACILITY_TYPE: Oil & Gas Location
INSPECTION_CATEGORY: Primary Facility
REGION: EP DOGO SWDO Dstr Off
COUNTY: Fayette
MUNICIPALITY: German Twp
INSPECTION_RESULT_DESCRIPTION: No Violations Noted
INSPECTION_COMMENT: HORIZONTAL MARCELLUS, Nabors drilling  on fluid @ 4,632' today (9/5/2015). Tripping out of hole drill pipe possible having circulation issues.

Location: 39.904611,-79.858172 <http://osm.org/go/ZWpaKHC~--?m=>

-------------------------
Source: Reuters Commodities: Energy

Natural Gas

Commodity Exchange Currency Expire Last Trade Trade Time Change Open Day's High Day's Low
NATURAL GAS CON1
Sep15
NYM USD 09/28 2.58 09/21 16:59 -0.03 2.59 2.60 2.55
Data as of5:30pm EDT (Delayed at least 20 minutes).
<http://www.reuters.com/finance/commodities/energy>

-------------------------
Notes:

Wampum Hardware is a company that receives blasting permits for seismic testing projects.

MARUSZEWSKI UNIT 1 is shown in DEP records as "Proposed But Never Materialized". A reasonable guess is that the notification for MARUSZEWSKI WELL SITES ESCGP-EXPEDITED is to indicate that "Atlas Resources LLC" does not intend to go forward with this well pad. (Though this is only speculation without seeing the actual application.) The original permit for MARUSZEWSKI WELL SITES ESCGP-EXPEDITED was issued 7/22/2010:
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=841545>

The original permit for
DC CONNECTOR PIPELINE was issued on 10/6/2011, authid 891836,
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=891836>

The original permit for MUTNANSKY 1469 TO 20/24" TRUNK was issued on 12/9/2011, authid 882855,
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=882855>

The original permit for CONSTANTINE TO LYNN PIPELINE was issued on 7/18/2011, authid 882228,
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=882228>

The original permit for CRISTOFEL WELL MCLS NO. 1510 was issued on 11/22/2011, authid 898642,
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=898642>

The original permit for LIPTAK WELL SITE was issued on 6/21/2012, authid 927838
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=927838>

The original permit for JACKSON FARMS WELL SITES was issued on 6/5/2009, authid 795112,
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=795112>

The original permit for BURNWORTH FRESHWATER IMPOUNDMENT was issued on 9/3/2010, authid 846597,
<http://www.ahs.dep.pa.gov/eFACTSWeb/searchResults_singleAuth.aspx?AuthID=846597>

Siegel 1 above was not listed on eNOTICE for this period, but the listing is being repeated to give the link to the full permit, which was not available at the time of the previous listing. We are starting to see a pattern where the Chevron well pads in Luzerne Twp are started with a permit for vertical Marcellus well before any of the permits for horizontal wells. One assumes "TVD" stands for Total Vertical Depth. The Siegel permit does not show a "vertical plan" as do permits for horizontal wells. It will be interesting to see what the plats for horizontal wells on this pad look like.

------------------------

DEP defines an environmental justice area as "any census tract where 20 percent or more individuals live in poverty, and/or 30 percent or more of the population is minority". (See:
<http://www.portal.state.pa.us/portal/server.pt/community/pa_environmental_justice_areas/20991>
<http://www.portal.state.pa.us/portal/server.pt/community/dep_enhanced_public_participation_policy/20988>
). There are supposed to be enhanced public participation requirements for permits in environmental justice areas, but news of this actually ever happening is scarce. In Fayette County, the entirety of Springhill, Nicholson, German, and Georges Townships are environmental justice areas, as well as a large part of Dunbar Township. DEP's policy document on public participation guidelines for environmental justice areas is located here:
<http://www.elibrary.dep.state.pa.us/dsweb/Get/Version-48671/012-0501-002.pdf>

eNOTICE records are likely to list the same permit multiple times, as that permit moves through the DEP process.

Oil & Gas Wells designated with a site a number and the letter H typically designate horizontal wells.

The eMapPa web site does not work in web browsers other than Internet Explorer. For instructions on how to view eMapPa data in Firefox send me E-mail.

-------------------------

Resources:

Pennsylvania Bulletin: <http://www.pabulletin.com/>

eNOTICE: <http://www.ahs2.dep.state.pa.us/eNOTICEWeb/>

DEP Well Details Report: <https://www.paoilandgasreporting.state.pa.us/publicreports/Modules/WellDetails/WellDetails.aspx>
Well Details may not show any information for new permits and will not show permits which have not yet been issued. Lookup for Well Details is by permit number.

DEP Permits Issued Detail Report:
<http://www.depreportingservices.state.pa.us/ReportServer/Pages/ReportViewer.aspx?/Oil_Gas/Permits_Issued_Detail>

DEP SPUD (drilling started) Report:
<http://www.depreportingservices.state.pa.us/ReportServer/Pages/ReportViewer.aspx?/Oil_Gas/Spud_External_Data>

DEP Oil and Gas Compliance Report:
<http://www.depreportingservices.state.pa.us/ReportServer/Pages/ReportViewer.aspx?/Oil_Gas/OG_Compliance>

DEP PA Oil & Gas Mapping:
<http://www.depgis.state.pa.us/PaOilAndGasMapping>

Pennsylvania Spatial Data Access:
<http://www.pasda.psu.edu/default.asp>
DEP Spatial Data Repository:
<ftp://www.pasda.psu.edu/pub/pasda/dep/>

National Response Center:
<http://www.nrc.uscg.mil/>

EPA-Echo: <http://www.epa-echo.gov/echo/compliance_report_air.html>

FERC citizen involvement: <http://www.ferc.gov/for-citizens/get-involved.asp>
To receive E-mail notification of all documents filed in a FERC docket, see:
<http://www.ferc.gov/docs-filing/esubscription.asp>

Follow the directions and enter the docket number to subscribe to.

Township  Supervisors receive information regarding Erosion & Sedimentation permits, and these records may be reviewable at township municipal offices.

DEP permits are reviewable through the File Review process, for application to do file review see: <http://www.portal.state.pa.us/portal/server.pt/community/southwest_regional_office/13775/file_review/593164>

Environmental Hearing Board: <http://ehb.courtapps.com/public/index.php>

PA DEP Environmental Policy Comment System:
<http://www.ahs.dep.pa.gov/eComment/>

Federal Register Environment: <https://www.federalregister.gov/environment>
Browsing of recent comment opportunities for federal agencies, e.g. EPA. Click "sign up" to subscribe to daily E-mails of new document listings.

SkyTruth Fayette County Drilling Alerts: <http://frack.skytruth.org/pennsylvania-frack-alerts/fayette_pa>

EPA Region 3 Water Protection Public Notices: <http://www.epa.gov/reg3wapd/public_notices.htm>
Marcellus Shale waste disposal injection wells in Pennsylvania are regulated directly by EPA, not DEP. Notice of any new permit applications will appear at the above web address.  I'm not aware of any subscription service to be notified of such applications. I'm not aware of any Marcellus Shale waste disposal injection wells in Fayette County (yet ...) but we need to monitor this page for future applications.

Energy Assurance Daily: <http://www.oe.netl.doe.gov/ead.aspx>
Daily newsletter from the US Department of Energy about events relating to energy. The Natural Gas section has information about pipelines.

-------------------------
Disclaimers:

This compilation from the above sources was done by hand using copy and paste and may omit relevant permits.

Does not currently include water supply permits. Does not include landfill permits even though many such are for Marcellus Shale waste. (It is not possible at this time to distinguish which landfill permits are for Marcellus Shale waste and which are not without doing File Review for each permit.)

Erosion & Sedimentation permit records do not currently include latitude and longitude. Where I am publishing latitude and longitude with E&S permits it is by inferring an associated well permit and using published latitude and longitude for the well. It is possible I may be inferring the wrong well site.

Municipalities are shown from eFACTS records on the DEP web site. The DEP has been known to list a municipality incorrectly.
